Precision Blanking

Why KSP is your precision multi-cut blank and sheet specialist.

Fast turnaround

EDI capability

Close tolerances

Precision blanks

Lighted inspections

Just-in-time delivery

Short runs/die trials

Electronic gauging

Ink stenciling capable

Wet or dry(non-oily)

Capabilities to cut up to 7 mults across

Paper interleaf

Pack turner

Hand shearing

Capabilities

PRECISION MULTI-CUT BLANKING
We produce precision blanks of exacting tolerances from coils—ready for your presses. Our process eliminates re-squaring and allows for optimum coil width.

CUSTOM MULTI-CUT SHEETING
You get the same advantages as with precision multi-cut blanking for less-stringent tolerances. Blanks are ready for standard die forming.

IN-LINE CORRECTIVE LEVELING
Our two-stage system features a roller leveler and a stretcher leveler that eliminates “edge wave” and “center buckle”. This produces stress free blanks with no spring back. This results in dead flat blanks for welding, forming, punching, laser cutting, etc.

MATERIAL WE PROCESS
Cold Rolled • Hot Rolled • Aluminum • Stainless Steel - 200 - 300 - 400 • Pre-Painted • Galvanized Steel • HSLA • Galvalume • Galvanneal • Aluminized Steel • Copper • Brass • Titanium • Tread Plate

STATISTICAL PROCESS CONTROL
For totally documented quality control per ISO standards.

CUSTOM PACKAGING
Designed and fabricated to your specifications. Extra sturdy wood pallets made in-house. Steel or Plastic banding. Heat Treating of pallets is available for export shipments.

PVC APPLICATION
Top and/or bottom.

CRANE CAPACITY
90,000 lbs.

CRITICALLY EXPOSED
We constantly monitor critically exposed surfaces that need to be defect free.

TOLERANCES

COIL INFO
Max. Weight 50,000 lbs.
Max. OD 84"
Min. ID 18"
Max. ID 24"
Min. Coil Width
Max. Coil Width
9.5"
73.5"
Stretcher Yield at Max. Gauge 50,000 psi. max.
MATERIAL
Gauge Range: 0.012" to 0.135"
Part Width:
Part Width Tolerance:
5" to 73.5 "
+/-0.005"
Part Length:
Part Length Tolerance:
8" to 310"
+/-0.015 up to 60"
Trim per Side: 0.25" to 2"
Minimum Slit Width: 3"
Max. Stack Weight: 20,000 lbs.
